KawasakiKLX230RSvsKawasakiKLX230

Kawasaki KLX 230RS vs Kawasaki KLX 230: Specifications Comparison

• Brakes, Suspension & Tyres

  Braking System, Calliper Type, Front Disc Size, Front Suspension Preload Adjuster

  Braking System	Dual Channel ABS	Dual Channel ABS
  Calliper Type	Fixed	Data Not Available
  Front Disc Size	213	290
  Front Tyre Pressure (Rider & Pillion)	26	Data Not Available
  Front Tyre Pressure (Rider)	26	Data Not Available
  Front Wheel Size	R12	R21
  Rear Tyre Pressure (Rider & Pillion)	33	Data Not Available
  Rear Tyre Pressure (Rider)	33	Data Not Available
  Rear Wheel Size	R18	R15
  Wheel Type	Spoke	Spoke
  Front Suspension	Telescopic Fork	Telescopic fork
  Rear Suspension	New Uni Trak Swingarm / 223 mm	Uni-Trak swingarm
  Front Tyre Size	80/100 R12	80/100 R21
  Rear Tyre Size	100/100 R18	100/100 R18
  Front Brake	Disc	Disc
  Rear Disc/Drum Size	240 mm	230 mm
  Rear Brake	Disc	Disc

  Collapse

• Comfort & Convenience

  Average Speed Indicator, Call/SMS Alerts, Geo Fencing, Low Battery Indicator

  Low Battery Indicator		Data Not Available
  Low Oil Indicator
  Start Type	Self Start	Self Start
  USB Charger Port		129
  Console Type	Digital	Digital
  Engine Kill Switch		Data Not Available
  Instrument Console	Digital	Digital
  Seat Style	Single	Single

  Collapse

• Engine & Transmission

  Gear Shifting Pattern, Spark Plugs, Engine Capacity, Engine Type

  Gear Shifting Pattern	1 Down 5 Up	Data Not Available
  Spark Plugs		Data Not Available
  Engine Capacity	233 cc	233 cc
  Engine Type	4-stroke single& SOHC& air-cooled	Air-cooled, 4-stroke, single-cylinder
  No. of Cylinders	1	1
  No. of valves per cylinder	2	2
  Transmission Type	Manual	Manual
  Top Speed	77 kmph	Data Not Available
  Bore x Stroke	67 mm x 66 mm	67.0 mm x 66.0 mm
  Configuration	SOHC	SOHC
  Cooling type	Air Cooled	Air-cooled
  Fuelling	Fuel Injection	Fi
  Max Power	19.57 bhp @ 8000 rpm	17.8 bhp @ 8000 rpm
  Max Torque	20.6 Nm @ 6000 rpm	18.3 Nm @ 6400 rpm
  Mileage (Claimed)	14 kmpl	Data Not Available
  Number of Gears	6 Speed	6 Speed

  Collapse

• Instrumentation

  Riding Modes Switch, Touch Screen Display, Fuel level guage, Gear Indicator

  Fuel level guage	Digital	Digital
  Tachometer	Digital	Digital
  Speedometer	Digital	Data Not Available
  Odometer	Digital	Digital
  Brightness Control	Data Not Available
  Tripmeter Type	Data Not Available	1
  No. of Tripmeters	Data Not Available	Digital

  Collapse

• Safety

  AHO (Automatic Headlight On), Hazard Warning Indicator, Hazard Warning Switch, Radial Tyres

  ABS - Anti-lock braking system
  Slipper Clutch		Data Not Available

  Collapse

• Dimensions & Capacity

  Length, Width, Height, Wheelbase

  Length	2035 mm	2050 mm
  Width	840 mm	830 mm
  Height	1205 mm	1180 mm
  Wheelbase	1435 mm	1370 mm
  Ground Clearance	275 mm	270 mm
  Fuel Tank Capacity	6.6 Litres	7.5 Litres
  Engine Oil Capacity	1.3 Litres	Data Not Available
  Body Type	Off Road	Dirt
  Unladden/Kerb Weight	129 kg	Data Not Available
  Seat Height	900 mm	900 mm

  Collapse

• Warranty

  Basic Warranty

  Basic Warranty

  2 Years/30000 kms

  3 Years/36000 Kms

  Collapse

• Pros & Cons

  Pros, Cons

  Pros	Lightweight frame improves trail manoeuvrability effectively. Strong suspension handles rough terrain confidently. Durable components ensure long-term off-road reliability. Responsive handling allows precise cornering on trails. Aggressive design enhances rugged off-road aesthetics.	Smooth engine torque supports versatile riding. Long‑travel suspension improves trail compliance. Upright ergonomics enhance rider comfort. Reliable build boosts overall dependability. Balanced setup suits mixed terrain use.
  Cons	No road legality limits street usability. Basic features reduce convenience for long rides. Seat and ergonomics limit long session comfort.	Limited top speed affects highway comfort. Basic features reduce tech appeal. Tire grip could improve on pavement.

  Collapse
