Hero Splendor Ismart 2016-18 Self Start Drum Brake Alloy Wheel

Hero Splendor iSmart Self Start Drum Brake Alloy Wheel image

55 kmpl
113.2 cc
9 bhp @ 7500 rpm
116 kg

Hero Splendor iSmart Self Start Drum Brake Alloy Wheel is Discontinued.

N/A

*Ex-Showroom Price(Price before discontinued)

Key Highlights of Splendor Ismart 2016-17 Self Start Drum Brake Alloy Wheel

Key	Specs Value
Number of gears	4 Speed
Seat Height	799 mm
Mileage	55 kmpl
Fuel Tank Capacity	9.5 Litres
Kerb Weight	116 kg

Hero Splendor iSmart Self Start Drum Brake Alloy Wheel Overview

Mileage: This variant claimed an ARAI Mileage of 55 kmpl.
Performance: It was powered by a 113.2 cc engine. The Air-cooled& 4-stroke& Single Cylinder& OHC puts out a power of 9 bhp @ 7500 rpm and generates a torque of 9.89 Nm @ 5500 rpm.
Specs & Features: Splendor Ismart 2016-17 Self Start Drum Brake Alloy Wheel comes with Pillion Footrest, Air Cooled Console Type, Engine Kill Switch, 1110 Handle Type, 2048 Instrument Console, Single Seat Style and Electric Start Start Type.

Brakes, Suspension & Tyres

Braking System	IBS
Front Disc Size	130
Front Tyre Pressure (Rider & Pillion)	25 psi
Front Tyre Pressure (Rider)	25 psi
Front Wheel Size	18 inch
Rear Tyre Pressure (Rider & Pillion)	41 psi
Rear Tyre Pressure (Rider)	28 psi
Rear Wheel Size	18 inch
Wheel Type	Alloy
Front Suspension	Telescopic Hydraulic Shock Absorbers
Rear Suspension	5-step Adjustable Hydraulic Shock Absorbers
Front Tyre Size	80/100 R18
Rear Tyre Size	80/100 R18
Front Type	Drum
Rear Disc/Drum Size	130 mm
Rear Type	Drum
Tubeless Tyres	Yes

Comfort & Convenience

Average Speed Indicator	No
Call/SMS Alerts	No
Front Storage Box	No
Geo Fencing	No
Low Battery Indicator	No
Low Oil Indicator	No
Pillion Backrest	No
Pillion Footrest	Yes
Riding Modes	No
Service Reminder Indicator	No
Under Seat Storage	No
GPS & Navigation	No
Console Type	Air Cooled
Distance to Empty Indicator	No
Engine Kill Switch	Yes
Handle Type	1110
Instrument Console	2048
Luggage Space	No
Seat Style	Single
Shutter Lock	No
Side Stand Indicator	No
Start Type	Electric Start
USB Charger Port	No

Engine & Transmission

Gear Shifting Pattern	Yes
Ignition	No
Spark Plugs	Yes
Engine Capacity	113.2 cc
Engine Type	Air-cooled& 4-stroke& Single Cylinder& OHC
No. of Cylinders	1
No. of valves per cylinder	2
Transmission Type	Manual
Range	522.5 km/charge
Top Speed	87 kmph
Charging Socket	No
Cooling type	Air Cooled
Fuelling	Fuel Injection
Max Power	9 bhp @ 7500 rpm
Max Torque	9.89 Nm @ 5500 rpm
Mileage (Claimed)	55 kmpl
Number of Gears	4 Speed

Instrumentation

Riding Modes Switch	No
Touch Screen Display	No
Fuel level guage	Digital
Gear Indicator	No
Tachometer	No
Speedometer	Analogue
Odometer	Digital

Safety

AHO (Automatic Headlight On)	Yes
Hazard Warning Indicator	No
Hazard Warning Switch	No
Radial Tyres	No
Side Stand Alarm	No
Pass Light	Yes
Pillion Grabrail	Yes
Turn Signal	No
ABS - Anti-lock braking system	Yes
Brake Assist	No
Power Modes	No
Slipper Clutch	Wet Multiplate
Traction Control System	No

Dimensions & Capacity

Length	2048 mm
Width	726 mm
Height	1110 mm
Wheelbase	1270 mm
Ground Clearance	180 mm
Fuel Tank Capacity	9.5 Litres
Engine Oil Capacity	Air-cooled, 4-stroke, Single Cylinder, OHC Litres
Body Type	Commuter
Seat Height	799 mm
Unladden/Kerb Weight	116 kg

Exterior

Daytime Running Lights	No
LED headlight	No

Body & Suspension

Frame Type

Tubular Double Cradle Frame

Entertainment & Communication

MID (Multi Info Display)
