TVS Flame 2009-2012 Specifications

TVS Flame 2009-2012 have 3 variants ranging from 49600 to 54700. Flame 2009-2012 is powered by a 1 cylinder, 124.8 cc, CCVTi& 3 Valve & 4 Stroke. It is able to produce 10 Nm@ 6000 rpm torque and 10.5 bhp @7500 rpm power.

TVS Flame 2009-2012 Safety Features

This Commuter bike comes loaded with Pass Light, Pillion Grabrail, Halogen Bulb Turn Signal from safety point of view.

TVS Flame 2009-2012 Weight & Height

The seat height of TVS Flame 2009-2012 is N/A and the kerb weight is 123 kg. In other dimensions Flame 2009-2012 has 2030 mm Length, 760 mm Width, 1070 mm Height, 1320 mm Wheelbase, 165 mm Ground Clearance, 7.5 Litres Fuel Tank Capacity , Commuter Body Type.

Comfort in TVS Flame 2009-2012

From Comfort perspective, Flame 2009-2012 have Pillion Footrest, Analogue and Digital Console Type, Single Seat Style.

TVS Flame 2009-2012 Body

TVS Flame 2009-2012 has 2.75 -18 front tyre and 100/90 R17 rear tyre. It comes with a Rigid Type frame and Alloy.

TVS Flame 2009-2012 Alternatives

Main Competitors of Flame 2009-2012 bike are Hero HF Deluxe, TVS Sport, Hero Splendor Plus, Hero Splendor Plus Xtec, Honda Shine 100, Honda Shine, Bajaj Platina 110, Hero HF 100, Bajaj Platina 100, TVS Radeon.

Keep scrolling to explore detailed configuration, features and technical specs of Flame 2009-2012.
Key HighlightsTVS Flame 2009-2012
Engine Capacity124.8 cc
Power10.5 bhp @7500 rpm
Weight123 kg
Read more

Explore more on TVS Flame 2009-2012

TVS Flame 2009-2012

TVS Flame 2009-2012

₹ 49,600 - ₹ 54,700 *
(Price before discontinued)
TVS Flame 2009-2012 is Discontinued.

Key Specifications of Flame 2009-2012

Number of gears4 Speed
Mileage65 kmpl
Fuel Tank Capacity7.5 Litres
Kerb Weight123 kg
Front Brake TypeDrum
Read more
Ad

Detailed Specifications of TVS Flame 2009-2012

Select Variants

Brakes, Suspension & Tyres

Braking SystemSynchronised Braking System (SBS)
Front Suspension Preload AdjusterNo
Front Tyre Pressure (Rider & Pillion)25 psi
Front Tyre Pressure (Rider)25 psi
Front Wheel Size17 inch
Rear Suspension Preload AdjusterYes
Rear Tyre Pressure (Rider)25 psi
Rear Wheel Size17 inch
Wheel TypeAlloy
Front Tyre Size2.75 -18
Rear Tyre Size100/90 R17
Front TypeDrum
Tubeless TyresYes
Tyre Size SpareNo

Comfort & Convenience

Call/SMS AlertsNo
Front Storage BoxNo
Geo FencingNo
Low Battery IndicatorNo
Low Oil IndicatorNo
Pillion BackrestNo
Pillion FootrestYes
Under Seat StorageNo
Console TypeAnalogue and Digital
Distance to Empty IndicatorNo
Engine Kill SwitchNo
Luggage SpaceNo
Seat StyleSingle

Engine & Transmission

Spark Plugs1 Per Cylinder
Engine Capacity124.8 cc
Engine TypeCCVTi& 3 Valve & 4 Stroke
No. of Cylinders1
No. of valves per cylinder2
Transmission TypeManual
Bore x StrokeNo
Charging SocketNo
ConfigurationSingle-Cylinder
Cooling typeAir Cooled
FuellingFuel Injection
Max Power 10.5 bhp @7500 rpm
Max Torque10 Nm@ 6000 rpm
Mileage (Claimed)65 kmpl
Number of Gears4 Speed

Instrumentation

Touch Screen DisplayNo
Fuel level guageYes

Safety

Radial TyresNo
Pass LightYes
Pillion GrabrailYes
Turn SignalHalogen Bulb
ABS - Anti-lock braking system No
Power ModesNo

Dimensions & Capacity

Length2030 mm
Width760 mm
Height1070 mm
Wheelbase1320 mm
Ground Clearance165 mm
Fuel Tank Capacity 7.5 Litres
Body TypeCommuter
Unladden/Kerb Weight123 kg

Body & Suspension

Frame TypeRigid Type
