Indian Motorcycle Springfield Dark Horse vs Harley-Davidson Breakout 117: Specifications Comparison

• Brakes, Suspension & Tyres

  Braking System, Calliper Type, Front Wheel Size, Rear Wheel Size

  Braking System	Dual Channel ABS	Dual Channel ABS
  Calliper Type	Fixed	Fixed
  Front Wheel Size	R19	B21
  Rear Wheel Size	R16	R18
  Wheel Type	Alloy	Alloy
  Front Suspension	Telescopic Fork	Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring
  Rear Suspension	Single Shock with Air Adjust	Hidden& free piston& coil-over moNoshock; 43mm stroke; toolless hydraulic preload adjustment
  Front Tyre Size	130/60 R19	130/60 B21
  Rear Tyre Size	180/60 R16	240/40 R18
  Front Brake	Disc	Disc
  Rear Disc/Drum Size	300 mm	292 mm
  Rear Brake	Disc	Disc
  Front Disc Size	Data Not Available	300
  Rear Suspension Preload Adjuster	Data Not Available
  Tubeless Tyres	Data Not Available

  Collapse

• Instrumentation

  Riding Modes Switch, Fuel level guage, Tachometer, Speedometer

  Riding Modes Switch
  Fuel level guage	Digital	Digital
  Tachometer	Digital	Digital
  Speedometer	Analogue	Digital
  Odometer	Digital	Digital
  Gear Indicator	Data Not Available

  Collapse

• Safety

  AHO (Automatic Headlight On), Side Stand Alarm, ABS - Anti-lock braking system , Hazard Warning Indicator

  AHO (Automatic Headlight On)
  Side Stand Alarm
  ABS - Anti-lock braking system
  Hazard Warning Indicator	Data Not Available
  Hazard Warning Switch	Data Not Available
  Radial Tyres	Data Not Available
  Pass Light	Data Not Available
  Pillion Grabrail	Data Not Available
  Turn Signal	Data Not Available	LED
  Slipper Clutch	Data Not Available
  Traction Control System	Data Not Available

  Collapse

• Engine & Transmission

  Engine Capacity, Engine Type, No. of Cylinders, No. of valves per cylinder

  Engine Capacity	1890 cc	1923 cc
  Engine Type	Thunder Stroke 116	Milwaukee Eight 117 Custom
  No. of Cylinders	2	Data Not Available
  No. of valves per cylinder	2	2
  Transmission Type	Manual	Manual
  Top Speed	115 kmph	Data Not Available
  Bore x Stroke	103 mm x 113 mm	103.5 mm x 114.3 mm
  Cooling type	Air Cooled	Data Not Available
  Fuelling	Fuel Injection	Fuel Injection
  Max Torque	168 Nm @ 2800 rpm	168 Nm @ 3000 rpm
  Mileage (Claimed)	20 kmpl	17.86 kmpl
  Number of Gears	6 Speed	6 Speed
  Gear Shifting Pattern	Data Not Available	1 Down 5 Up
  Max Power	Data Not Available	103.3 bhp @ 5020 rpm

  Collapse

• Dimensions & Capacity

  Length, Width, Height, Wheelbase

  Length	2522 mm	2370 mm
  Width	1000 mm	950 mm
  Height	1261 mm	Data Not Available
  Wheelbase	1701 mm	Data Not Available
  Ground Clearance	142 mm	Data Not Available
  Fuel Tank Capacity	20.8 Litres	Data Not Available
  Engine Oil Capacity	5.2 Litres	4.7 Litres
  Body Type	Tourer	Cruiser
  Unladden/Kerb Weight	358 kg	296 kg
  Seat Height	660 mm	665 mm

  Collapse

• Comfort & Convenience

  Start Type, Console Type, Distance to Empty Indicator, Instrument Console

  Start Type	Self Start	Self Start
  Console Type	Analogue Cum Digital	Digital
  Distance to Empty Indicator
  Instrument Console	Digital	Digital
  Low Battery Indicator	Data Not Available
  Low Oil Indicator	Data Not Available
  Pillion Footrest	Data Not Available
  Service Reminder Indicator	Data Not Available
  USB Charger Port	Data Not Available
  Engine Kill Switch	Data Not Available
  Side Stand Indicator	Data Not Available

  Collapse

• Pros & Cons

  Pros, Cons

  Pros	cruise control Powerful Engine - air-cooled 116 ci V-twin Ride Mode	Strong 1923cc Milwaukee-Eight 117 engine with massive torque Incredible road presence and standout design Comfortable low seat height (665 mm) Relaxed cruising ergonomics Premium build quality and brand appeal
  Cons	Heavy Weight Low Mileage Price is too high	Very heavy (~309–310 kg) Limited cornering clearance and handling Expensive to buy and maintain Not ideal for city traffic Basic feature set for the price

  Collapse

• Exterior

  Daytime Running Lights, LED headlight

  Daytime Running Lights	Data Not Available
  LED headlight	Data Not Available

  Collapse

• Warranty

  Basic Warranty

  Basic Warranty

  Data Not Available

  2 Years/ Unlimited kms

  Collapse
