Honda Bike Dio Specifications

In the market for a new Honda Bike Dio scooter? Have a look at its comprehensive specification list including engine, dimensions, electricals, tyres and more

Read More

Honda Bike Dio

₹ 63,273 - ₹ 69,171

Don't miss out on Latest Offers!

Key Specifications

TitleSpecification
Displacement109.51
Max Torque (nm@rpm)9 Nm @ 4750 rpm
Max Power (bhp @ rpm)7.76 PS @ 8000 rpm
Number of gearsCVT
Seat Height650 mm
Fuel Tank Size5.3 Litres
Curb Weight105 Kg
Tyre Size Front90/90-12
Tyre Size Rear90/100-10
Cooling TypeAir Cooled

Key Features

TitleSpecification
Front SuspensionTelescopic Suspension
Front TypeDrum
Rear Suspension3-Step Adjustable& Spring Loaded Hydraulic
Rear TypeDrum
Tyre Size90/100-10
Seat StyleSingle
Wheel TypeAlloy Wheels

Honda Bike Dio Specifications

Safety

ABS - Anti-lock braking system No
Brake AssistNo
Power ModesNo
Slipper ClutchYes
Traction Control SystemNo

Body

Body TypeScooter

Engine

Bore x Stroke47.0 mm x 63.1 mm
ConfigurationSingle Cylinder
Cooling typeAir Cooled
No of Cylinders1
Engine Capacity109.51
Engine TypeFan Cooled& 4 Stroke& SI Engine
FuellingYes
Max Power 7.76 PS @ 8000 rpm
Max Torque9 Nm @ 4750 rpm
Mileage (Claimed)55
No of valves per cylinder2

Comfort & Convenience

Charging SocketNo
Engine Kill SwitchYes
Seat StyleSingle

Transmission

Clutch TypeAutomatic
Number of GearsCVT
TypeAutomatic

Instrument Console

Console TypeAnalogue
Distance to Empty IndicatorYes
MID (Multi Info Display)No
Side Stand IndicatorYes

Chassis and Suspension

Frame TypeUnder Bone

Brakes

Front Disc/Drum Size130 mm
Front TypeDrum
Rear Disc/Drum Size130 mm
Rear TypeDrum

Suspensions/Brakes/Wheels and Tyres

Suspension - FrontTelescopic Suspension
Front Tyre Size90/90-12
Suspension - Rear 3-Step Adjustable& Spring Loaded Hydraulic
Rear Tyre Size90/100-10
Tyre Size SpareNo

Instrumentation

Fuel level guageYes
OdometerAnalogue
SpeedometerAnalogue
TachometerNo

Dimensions

Fuel Tank Capacity 5.3 Litres
Seat Height650 mm
Unladden/Kerb Weight105 Kg

Dimensions and Weights

Ground Clearance160 mm
Height1150 mm
Length1808 mm
Wheelbase1260 mm
Width723 mm

Electricals

Start TypeKick & Self Start

Tyres and Wheel

Wheel TypeAlloy Wheels
